TECPEL CO., LTD.
Product Guide
Phase Sequence Indicator PHS-863
Digital Megohm/Insulation Meter  DIM-570
Digital Insulation Meter DIM-571

Digital Insulation Tester
Features :
  • Measure insulation resistance up to 2000MΩ
  • 1000V pulse to test insulation
  • 3 1/2 Digit LCD Back light display
  • Auto data hold function after releasing
    MEAS button
  • Auto power off function
  • Portability and simplicity for one hand
    operation
  • Valox housing to withstand accidental drops
FEATURES:
  • DIM 571 is a LCD Indicated instruments for
insulation (M Ohm), Continuity (OHM) and
AC Voltage
  • Three Insulation test voltage (DCV):
250V, 500V, 1,000V.
  • Large LCD display(68 x 34mm)
  • Test Insulation at rated voltate into 1 1mA load
  • 200mA short circuit continuity current.
  • Timer for test functions (3 ~ 5 minutes)
  • Data Hold function
  • Auto power off function
  • Automatic circuit dischage
  • Fuse proection
  • EN61010 CAT III 600V
  • BS 16" Edition
  • Features:
  • Measures down to 0.01 Ohm.
  • 3 Earth Ranges: 20, 200, 2000 Ohm
  • One test current of 2 mA RMS.
  • Indication if resistance of auxiliary spikes
resistance is within range.
  • Two or three-terminal measurement.
  • Three-terminal measurement for earth
electrode testing.
  • Large LCD display.
  • Data hold function.
  • Calibration performed with supplied test leads
(3 T fully compensated).
  • Measure earth voltage up to 200V AC.
  • Simple to use and lower power.
  • Open loop indication with " 1 " (MSD) on display
and LED Light off.
  • Two functions in one unit includng open phase
and phase sequence.
  • Large size alligator clips : able to clip on
switch-board terminals easily.
  • Identify 3 phase sequence and open
phase check
  • Applications: This model is ideal for installing
conveyor lines, pump systems and
interconnected drivers.
  • Safety Approval:  EN 6101-1 CAT. III.
EN 61010-2-031
Earth Resistance Tester ERT-580
Megom Insulation Tester Insulation meter dim-570
Insulaiton Meter Tester DIM-571
Earth Resistance Tester ERT-580
Phase sequence indicator PHS-863
Digital Loop Impedance PSC tester

Digital Loop impedance PSC tester  LP-2811
LP-2811 Features:
  • Loop Impedance Range L - E , L - N:
20/200/2000 Ohm (Auto-Range)
  • Loop Impedance Test Current : 12A at
    230V/50Hz
  • Voltage Measurement L-N, L-E : 80 to 250V
    AC/50Hz
  • Earth wire / path Return Resistance :
20/200/2000 Ohm (Auto-Range)
  • Neutral Wire Resistance :
20/200/2000 Ohm (Auto-Range)
  • Line Wire Resistance&Transformer Windings :
20/200/2000 Ohm (Auto-Range)
  • PSC Current (L - N) Max : 3kA
  • PSC Current (L - N) Max : 3kA
  • Operating Voltage : 230V +/-20%Hz
Personal Safety Voltage detector

Personal Safety Voltage Detector
Model: SVD-588
  • Warning Proximity of AC Voltage
  • Water Proof (sealed to Ip65)
  • Easty to wear on body, Belt, Helmet.
  • Ultra High bright LED indicaiton
  • Test and Diagnostic Circuitry.
  • Freiendly priority alert reporting.
  • Circuit Test Funciton.
  • Hight impact type casing.
  • Differnt alerting sound and light.
  • removable neck belt.
  • suitable for indoor and outdoor use.
  • Detect voltage on any systems.
  • Low battery indiation.,
  • All OK test indication.
  • Ultra low power consumption.
Cable Tracer Tone generator Amplifer probe

Cable Tracer (Tone Generator /
Amplifier probe)  CT-581
Amplifer Probe (CT-581A)
The amplifier probe indentifies and traces wires or
cables within a group. Without damaging the insulation
Works with any Tone Generator to indentify wires.
  • Adjustable volume to suit work environment.
  • A plug receptable for headset or hand set.
  • Work with 9V battery and come
with soft carrying case
Tone Generator( CT-581G)
  • A great tool for locating and identifying cable pairs
    or individual conductors.
  • Serves as a continuity and polarity tester
  • A three-colored LED display for test result.
